Winter Coaster Caddy & Ice Lattice Holder
6/8/2026 Parametric
Winter Coaster Caddy & Ice Lattice Holder
A geometric desk coaster holder featuring a mathematically generated Voronoi ice lattice pattern carved into the outer perimeter wall, with a front ergonomic retrieval cutout.
⚙️ Key Parametric Variables
| Parameter | Default | Range | Description |
|---|---|---|---|
coaster_diameter | 90mm | 60mm - 120mm | Inner diameter matching your coaster set. |
coaster_stack_qty | 6 | 2 - 12 | Total number of coasters intended to be stacked. |
slot_tolerance | 1.5mm | 0.5mm - 4.0mm | Radial clearance to prevent coasters from jamming. |
lattice_frequency | 12 | 6 - 24 | Density of geometric lattice windows around the perimeter. |
thumb_cutout_width | 35mm | 20mm - 60mm | Width of the front finger removal notch. |
🖨️ 3D Printing Recommendations
- Material: PLA, Matte PLA, or Wood-Filled PLA.
- Layer Height:
0.20mmfor crisp bridge spans across lattice windows. - Perimeters:
3 walls. - Infill:
15% Gyroid. - Retraction: Ensure your retraction settings are tuned (0.8mm direct drive / 4.5mm Bowden) to prevent stringing across the lattice cutouts.
Get Source Files £3
Support the creator and unlock the raw `.scad` source code and high-res print-ready STL files for this design.
Purchase on Ko-FiCOMING SOON
Live Editor
Launch our cloud-powered OpenSCAD compiler to tweak parameters and preview custom dimensions directly in your browser.
Secure processing via Ko-fi
Variants
Render Time: --
All STL files are free to download and access. Donations are completely optional. All money given helps AHM Labs R&D provide more tools and open-source software.
